DLW140
DLW140
18V X2 (36V) LXT BL 355 mm (14″) Toolless Portable Cut-Off
- World’s First Cordless Portable Cut-off
- Cuts 130 metal studs with BL1850B x2
- Electric brake allows adjustments to be completed faster for maximum productivity
- Load status indicator shows the load level on the motor during cutting operation
- Suitable for light duty application, such as cutting metal studs
- BL motor generates less heat buildup and is ideal for prolonged use in high production applications
- BL motor is electronically controlled to optimize battery energy use for longer run time per charge
- BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
- Toolless flange removal for quick and easy wheel changes
- Toolless fence and vise controls for quick and easy adjustments to varied needs
- Large spark guard captures and deflects debris away from the surrounding area
- Quick release vise for secure stock retention and fast repeated cut offs
- D-shape handle for user comfort
- Carry handle for easy transport to job site
- Pin type saw head locking device for storage and transport
- Lock-off button prevents accidental start up (country-specific)
- Soft start suppresses start-up reaction for smooth start-ups and longer gear life
| Wheel Diameter | 355 mm (14") |
|---|---|
| Hole Diameter | 25.4 mm (1") |
| Max Wheel Thickness | 3 mm (1/8") |
| No Load Speed (RPM) | 3,800 |
| Capacity at 90° | Round: 127 mm (5"); Rectangular: 115×130 mm (4-1/2"x5-1/8"); Rectangular: 102×194 mm (4"x7-5/8"); Rectangular: 70×233 mm (2-3/4"x9-1/8"); Square: 119×119 mm (4-11/16"x4-11/16"); Triangular: 137×137 mm (5-3/8"x5-3/8") |
| Capacity at 45° | Round: 127 mm (5"); Rectangular: 115×103 mm (4-1/2"x4-1/16"); Square: 106×106 mm (4-3/16"x4-3/16"); Triangular: 100×100 mm (4"x4") |
| Max Output | 1,300 W |
| Vibration Level | 2.5 m/s² |
| Vibration K Factor | 1.5 m/s² |
| Sound Pressure Level | 103 dB(A) |
| Sound Power Level | 115 dB(A) |
| Noise K Factor | 3 dB(A) |
| Dimensions (L x W x H) | w/ European type safety guard: 537x290x640 mm (21-1/8"x11-3/8"x25-1/4"); w/ Safety guard other than European type: 537x280x640 mm (21-1/8"x11"x25-1/4"); w/ Center cap type safety guard: 537x280x640 mm (21-1/8"x11"x25-1/4") |
| Net weight | 17.2 – 17.8 kg (37.9 – 39.3 lbs.) |
